TE Connectivity Macro Sensors

HGSI is a factory authorized HGSI is a factory authorized distributor of TE Connectivity Macro Sensors products. TE Connectivity Macro Sensors offers a complete range of Linear Variable Differential (LVDT) absolute position transducers and signal conditioning electronics. Order online today for fast delivery. Our skilled application engineers are standing by to assist with pricing and technical questions.

Pricing or Technical Questions?Contact Us

• Push-button auto-calibration
• Analog voltage or current output
• Digital RS-485 interface
• Supports most standard AC LVDTs, RVDTs, and VR half-bridge sensors
• DIN-rail mountable

Discontinued

LVC-2500 HAS BEEN DISCONTINUED

• Replaced by model LVC-4000

Discontinued

MME-1000 HAS BEEN DISCONTINUED

• Replaced by model LVC-4000

Discontinued

BBP-315 HAS BEEN DISCONTINUED

Replaced by model GBP-315-A

Discontinued

BBP-375 HAS BEEN DISCONTINUED

Replaced by model GBP-375-A

Discontinued

BBT-375 HAS BEEN DISCONTINUED

Replaced by model GBT-375-A

• Miniature 3/8 inch size, low core mass
• Ranges of ±0.025 inch to ±1.0 inches
• Non-linearity less than ±0.25% of FRO
• 220°F (105°C) operating temperature
• Coil assembly sealed to IEC IP-61
• Magnetically shielded SS housing

• Industry-standard 3/4 inch [19 mm] diameter

• Ranges of ±0.05" to ±10" (DC 750) or 0.100" to 20.00" (SE 750)

• ±15 V DC input, 0 to ±10 V DC output (DC 750)

• 24 V DC input, true 0-10 V DC output (SE 750)

• Non-linearity less than or equal to ±0.25% of FSO (less than or equal to ±0.10% optional on SE 750)

• Ranges of ±0.050 inch to ±2.00 inches

• Repeatability of 0.01% of FRO

• Non-linearity less than ±0.25% of FRO

• Coil environmentally sealed to IEC IP-68

• Ranges of ±0.050 inch to ±2.00 inches

• Repeatability of 0.01% of FRO

• Non-linearity less than ±0.25% of FRO

• Coil environmentally sealed to IEC IP-68

• Low pressure air-extend/spring-retract plunger

• Ranges of ±0.050 inch to ±2.00 inches

• Non-linearity less than ±0.25% of FRO

• Repeatability of ±0.01% of FRO

• Radial connector with mating plug included

• Coil environmentally sealed to IEC IP-68

• Ranges of ±0.020 inch to ±2.00 inches

• ±15 V DC input, pre-calibrated 0 to ±10 V DC output  Repeatability <0.01% of FRO

• Non-linearity less than ±0.25% of FRO  Coil environmentally sealed to IEC IP-68

• Ranges of ±0.020 inch to ±2.00 inches

• ±15 V DC input, pre-calibrated 0 to ±10 V DC output  Repeatability <0.01% of FRO

• Non-linearity less than ±0.25% of FRO

• Coil environmentally sealed to IEC IP-68

• Ranges of ±0.020 inch to ±2.00 inches

• ±15 V DC input, pre-calibrated 0 to ±10 V DC output

• Repeatability <0.01% of FRO  Non-linearity less than ±0.25% of FRO

• Coil environmentally sealed to IEC IP-68

• Ranges of 0.100 inch to 4.00 inches  Non-linearity less than ±0.10%

• Repeatability OF <0.01%  0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction

• Coil environmentally sealed to IEC IP-68

• Axial or radial connectors w/ mating plug included

• Air-extend/spring-retract option

ElectronicComponents

• Ranges of 0.100 inch to 4.00 inches
• Radial connector, mating plug included
• 24 V DC input, precalibrated 0 to 10 V DC output
• Repeatability of 0.000025 inch
• Non-linearity less than ±0.25% of FRO
• Coil environmentally sealed to IEC IP-68
• Through-bore design

ElectronicComponents

• Ranges of 0.100 inch to 2.00 inches
• Radial connector, mating plug included
• Air Extend, Spring Retract
• 24 V DC input, precalibrated 0 to 10 V DC output
• Repeatability of 0.000025 inch
• Non-linearity less than ±0.25% of FRO
• Coil environmentally sealed to IEC IP-68
• Through-bore design

• Ranges of 0.100 inch to 4.00 inches

• Non-linearity less than ±0.10%

• Repeatability OF <0.01%, 0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction, Coil environmentally sealed to IEC IP-68

• Axial or radial connectors w/ mating plug included, Air-extend/spring-retract option

• Ranges of 0.100 inch to 4.00 inches  Non-linearity less than ±0.10%

• Repeatability OF <0.01%

• 0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction, Coil environmentally sealed to IEC IP-68

• Axial or radial connectors w/ mating plug included, Air-extend/spring-retract option

• Ranges of 0.100 inch to 4.00 inches  Non-linearity less than ±0.10%

• Repeatability OF <0.01%  0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction, Coil environmentally sealed to IEC IP-68

• Axial or radial connectors w/ mating plug included, Air-extend/spring-retract option

• Standard 3/4 inch (19 mm) diameter

• Ranges of ±0.10 inches to ±0.30 inches

• Non-linearity less than ±0.5% of FRO

• 220°F (105°C) operating temperature

• AGD number 9 hardened contact tip

• UL/ULc listed

•  Ranges of ±1 inch to ±10 inches

• All stainless steel construction

• 1/2″ conduit leads outlet

• Ranges of ±0.050 inch to ±10.0 inches

• Environmentally sealed to IEC IP-68

• Non-linearity less than ±0.25% of FRO

• Ranges of ±0.050 inch to ±10.0 inches

• Environmentally sealed to IEC IP-68

• Non-linearity less than ±0.25% of FRO

• Ranges of ±0.050 inch to ±10.0 inches

• In-line connector, mating plug included

• Environmentally sealed to IEC IP-68

• ±15 V DC input, pre-calibrated 0 to ±10 V DC output

• Non-linearity less than ±0.25% of FRO

• Ranges of ±0.050 inch to ±10.0 inches

• Radial connector, mating plug included

• Environmentally sealed to IEC IP-68

• ±15 V DC input, precalibrated 0 to ±10 V DC output

• Non-linearity less than ±0.25% of FRO

• Ranges of 0.100 inch to 20.00 inches

• Non-linearity less than ±0.25% (±0.10% optional)

• Repeatability of 0.000050 inch  0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction

• Coil environmentally sealed to IEC IP-68, Axial or radial connectors w/ mating plug included

• Ranges of 0.100 inch to 20.00 inches

• Non-linearity less than ±0.25% (±0.10% optional)

• Repeatability of 0.000050 inch

• 0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction, Coil environmentally sealed to IEC IP-68

•  Axial or radial connectors w/ mating plug included

• Ranges of 0.100 inch to 20.00 inches

• Non-linearity less than ±0.25% (±0.10% optional)

• Repeatability of 0.000050 inch

• 0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction, Coil environmentally sealed to IEC IP-68

• Axial or radial connectors w/ mating plug included

• Ranges of 0.100 inch to 20.00 inches

• Non-linearity less than ±0.25% (±0.10% optional)

• Repeatability of 0.000050 inch

• 0-10VDC or 4-20mA outputs

• Rugged, stainless steel construction

• Coil environmentally sealed to IEC IP-68  Axial or radial connectors w/ mating plug included

• Ranges of ±0.050 inch to ±10.0 inches
• 400°F (200°C) operating temperature
• In-line connector, mating plug included
• Environmentally sealed to IEC IP-68
• Non-linearity less than ±0.25% of FRO

• Ranges of ±0.05" to ±10" [±1.25 mm to ±250 mm]

• 400°F (200°C) operating temperature

• Environmentally sealed to IEC IP-68

• Non-linearity less than ±0.25% of FRO

• Through-bore design (HSTAR)

• Mating plug for connector included

• Standard 3/4 inch (19 mm) diameter
• Ranges of ±0.050 inch to ±10 inches
• Non-linearity less than ±0.25% of FRO
• 220°F (105°C) operating temperature
• Coil assembly sealed to IEC IP-61
• Magnetically-shielded SS housing

• 0.812 inch diameter replacement units

• Ranges of ±0.050 inch to ±10 inches

• Non-linearity less than ±0.25% of FRO

• 220°F (105°C) operating temperature

• Coil assembly sealed to IEC IP-61

• Magnetically shielded SS housing

• 0.812 inch diameter legacy replacements

• Ranges of ±0.050 inch to ±10 inches

• 0.062 inch radial core-to-bore clearance

• Non-linearity less than ±0.25% of FRO

• 300°F (150°C) operating temperature

• Coil assembly sealed to IEC IP-61

• Magnetically shielded SS housing

• Ranges of 0.100 inch to 20.00 inches

• 24 V DC input, precalibrated 0 to 10 V DC output

• Non-linearity less than or equal to ±0.25% of FSO (less than or equal to ±0.10% optional)

• Industry-standard 3/4 inch (19 mm) diameter

• Through-bore design

• Sealed to IEC IP-62

• Rugged, heavy duty construction

• Ranges of ±0.50 inches to ±10.00 inches

• Non-linearity less than ±0.25% of FRO

• 300°F (150°C) operating temperature

• Assembly sealed to IEC IP-64
