LPPS-36B Linear Potentiometer Position Sensor with Rod End Joints

Product Description

The LPPS-36B Ruggedized Linear Potentiometer Position Sensor is engineered for applications requiring extended measurement ranges and superior durability in demanding industrial environments. With its robust 36mm diameter housing and heavy-duty construction, this versatile sensor delivers reliable position feedback for long-stroke applications while maintaining excellent resistance to environmental challenges. Featuring sturdy rod end joints with 8mm thru-holes for secure installation, the LPPS-36B combines extended range capability with industrial-grade performance for applications ranging from heavy machinery to large-scale industrial systems.

• Available in extended stroke lengths from 350 to 700 mm (14 to 28 inches)

• Heavy-duty rod end joints with 8mm thru-holes for secure mounting

• Ratiometric output for accurate measurement across long strokes

• Anodized aluminum housing for superior corrosion resistance

• IP61 rated for dust-tight and water-resistant operation

• Robust 1.4" (36mm) OD housing for industrial durability

The LPPS-36B is ideally suited for heavy equipment monitoring, industrial press systems, large-scale automation, and extended-range position feedback applications where durability and measurement length are paramount.

Industrial Performance

Heavy-Duty Design for Extended Ranges

The LPPS-36B Linear Potentiometer Position Sensor is specifically engineered for applications requiring longer measurement ranges and enhanced durability. Its substantial 36mm diameter profile provides the structural integrity necessary for extended stroke lengths up to 700mm, delivering reliable operation in environments where standard sensors might be insufficient. The robust construction ensures consistent performance in applications with significant mechanical stress, vibration, and environmental challenges.

Long-Stroke Measurement Technology

The LPPS-36B utilizes a high-quality conductive plastic resistive element optimized for extended measurement ranges. Its ratiometric output (0% to 100% of excitation voltage) ensures accurate position data across the entire stroke length, maintaining precision even at the extremes of its operational range. This extended measurement capability makes the LPPS-36B ideal for applications requiring longer travel feedback with industrial-grade reliability.

Applications

Heavy Equipment Systems

The LPPS-36B excels in heavy equipment applications:

Construction Machinery

In construction equipment, the LPPS-36B provides critical position feedback for extended hydraulic systems, boom positions, and attachment control. The robust housing and secure 8mm rod end joints accommodate the substantial forces encountered in heavy machinery operation.

Agricultural Equipment

For agricultural machinery, the LPPS-36B's extended stroke ranges and durability make it ideal for monitoring implement positions, hydraulic systems, and automated control mechanisms across long operational ranges.

Industrial Manufacturing

The LPPS-36B delivers exceptional performance in manufacturing environments:

Large-Scale Presses

In industrial press operations, the LPPS-36B provides precise position monitoring across substantial travel distances, enabling accurate control and safety monitoring of large mechanical systems.

Material Handling Systems

For extensive material handling equipment, the extended range capabilities of the LPPS-36B allow for continuous monitoring of long-travel components such as conveyors, lifts, and transfer systems.

Fluid Power Systems

The durability and extended range of the LPPS-36B make it ideal for fluid power applications:

Hydraulic Cylinder Monitoring

The sensor excels in long-stroke hydraulic cylinder position sensing, where the 8mm rod end joints facilitate direct installation on cylinder mounting points while accommodating significant mechanical loads.

Large Valve Systems

For industrial valve systems requiring extended travel monitoring, the LPPS-36B provides reliable position feedback for improved control and diagnostic capabilities.

Research and Testing

The extended range and precision of the LPPS-36B suit it for specialized research applications:

Structural Testing

In structural and materials testing, the LPPS-36B can monitor displacements across extended ranges with consistent accuracy, providing valuable data for research and quality control.

Motion Analysis

For large-scale motion analysis systems, the extended stroke lengths available with the LPPS-36B enable comprehensive monitoring of mechanical movement across substantial distances.

Installation and Integration

Mounting Options

The heavy-duty rod end joints of the LPPS-36B provide secure mounting capabilities:

• Direct connection to substantial mechanical linkages through 8mm thru-holes

• Integration with large hydraulic cylinders and actuators

• Attachment to heavy-duty moving components

• Secure positioning in high-vibration environments

Electrical Specifications

The LPPS-36B features straightforward electrical connections:

• Ratiometric output proportional to position (0-100% of excitation voltage)

• Conductive plastic resistive element for extended operational life

• Simple three-wire configuration

• Compatible with standard industrial controllers and monitoring systems

System Integration

For maximum performance, the LPPS-36B can be integrated with:

• Heavy equipment control systems

• Factory automation controllers

• Data acquisition systems for industrial processes

• Predictive maintenance monitoring equipment

• Safety and position verification systems

Durability Features

The LPPS-36B is built to withstand the most challenging environments:

• Anodized aluminum housing for superior corrosion resistance

• IP61 environmental rating for protection against dust and water

• Industrial-grade materials resistant to temperature extremes

• Robust construction to withstand significant shock and vibration

• Designed for reliable operation in harsh industrial conditions

Customization Options

The LPPS-36B can be tailored to meet specific application requirements:

• Various stroke lengths from 350mm to 700mm

• Custom cable specifications including length and termination

• Modified mounting configurations for specialized installations

• Enhanced environmental protection for extreme applications

Construction Quality

The LPPS-36B is manufactured with industrial durability as a core design principle. Its substantial anodized aluminum housing provides excellent corrosion resistance and mechanical integrity, while the IP61 environmental rating ensures protection against dust and water intrusion. This thoughtful construction ensures reliable operation even in the most demanding industrial environments where extended measurement ranges are required.

Conclusion: Extended-Range Position Sensing for Industrial Applications

The LPPS-36B Ruggedized Linear Potentiometer Position Sensor with rod end joints represents an ideal solution for applications requiring longer measurement ranges combined with industrial-grade durability. Its robust design and extended stroke capabilities make it particularly suitable for demanding applications across heavy equipment, manufacturing, fluid power, and research sectors.

By incorporating this sensor into your systems, you benefit from:

• Extended measurement ranges from 350mm to 700mm

• Industrial-grade durability with 36mm diameter housing

• Secure mounting through heavy-duty 8mm rod end joints

• Precise position measurement with reliable ratiometric output

• Robust construction for consistent long-term operation in challenging environments

• Versatility across multiple industrial application domains

For engineers and system designers seeking reliable extended-range position feedback solutions, the LPPS-36B offers proven technology with the durability and measurement capability to meet the most demanding industrial requirements.
